ASHATA 4G Portable Router ASHATA3ethc05m91 User Manual

1. Ynlieding en oerview

This manual provides comprehensive instructions for the ASHATA 4G Portable Router, Model ASHATA3ethc05m91. This device is a versatile mobile hotspot designed to provide reliable internet access for multiple users. It supports various 4G networks and offers high-speed connectivity, making it ideal for travel, outdoor activities, or as a portable internet solution. The router features a built-in 3000mAh battery and is powered via a Type-C port, ensuring convenience and portability.

Image 1.1: The ASHATA Portable Pocket WiFi Router, highlighting its compact design, Type-C interface, and 3000mAh battery capacity.

2. Package Ynhâld

Kontrolearje asjebleaft oft alle hjirûnder neamde items yn jo pakket opnommen binne:

• 1 x ASHATA Portable Router
• 1 x USB Type-C Supply Cord
• 1 x Ynstruksjehânlieding (Dit dokumint)

3. Produktfunksjes

The ASHATA 4G Portable Router offers a range of features designed for optimal mobile connectivity:

• Share Up to 10 Users: Supports multiple 4G networks, enabling internet sharing for up to 10 connected devices simultaneously.
• Fleksibele krêftopsjes: Powered conveniently by devices with Type-C ports, such as cell phone chargers, car chargers, or mobile power banks.
• Plug and Play-operaasje: Simple setup allows immediate 4G network access. Just insert a SIM card and connect to a power source.
• Ferbining mei hege snelheid: Achieves 4G LTE speeds of up to 300Mbps, providing fast and stable internet access.
• Multi-Terminal Support: Connects up to 8 devices, including cell phones, tablets, laptops, computers, and smart TVs.
• Feilige fersifering: Features WPA/WPA2 encryption for enhanced network security, protecting against unauthorized access.

Image 3.1: Visual representation of the router's key advantages, including its 3000mAh battery, WiFi support, 4G connectivity, portability, Type-C charging, and sleek design.

4. Setup Guide

Follow these steps to set up your ASHATA 4G Portable Router:

1. SIM-kaart ynfoegje: Locate the SIM card slot on the router. Carefully insert a standard SIM card (not included) into the designated slot until it clicks into place. Ensure the SIM card is correctly oriented.
2. Ferbine macht: Connect the provided USB Type-C supply cord to the router's Type-C port and plug the other end into a compatible power source (e.g., a USB wall adapter, car charger, or power bank).
3. Power On: Press and hold the power button (refer to Image 4.1 for location) for a few seconds until the device powers on and the display illuminates.
4. Earste opstart: The router will perform an initial boot-up sequence. The display will show network status, signal strength, and battery level. Wait for the network indicator to show a stable 4G connection.

Ofbylding 4.1: In detaillearre view of the router's side, indicating the Type-C charging port, WPS button, power button, and the location of the SIM card slot for insertion.

5. Bedriuwsinstruksjes

Once the router is set up and powered on, you can begin using its mobile hotspot functionality:

1. Connect Devices via Wi-Fi:
   • On your Wi-Fi enabled device (phone, tablet, laptop), search for available Wi-Fi networks.
   • Select the network name (SSID) displayed on the router's screen.
   • Enter the Wi-Fi password (Key) also displayed on the router's screen when prompted.
   • Your device should now be connected to the internet through the router.
2. Tafersjochstatus: The router's display provides real-time information including signal strength, battery level, number of connected users, and data usage.
3. Charging the Router: When the battery is low, connect the router to a power source using the Type-C cable. The battery indicator on the display will show charging status.
4. Feiligensfunksjes: The router uses WPA/WPA2 encryption to secure your wireless network. It is recommended to keep the default password or change it to a strong, unique password for optimal security.

Image 5.1: The router demonstrating its capability to connect up to 10 devices simultaneously, including smartphones, tablets, and laptops.

Image 5.2: An illustration emphasizing the router's security features, specifically WPA/WPA2 encryption, for a more secure network environment.

6. Underhâld

To ensure the longevity and optimal performance of your ASHATA 4G Portable Router, follow these maintenance guidelines:

• Hâld droech: Foarkom dat it apparaat bleatsteld wurdt oan wetter, focht of hege luchtvochtigheid.
• Temperatuerkontrôle: Do not expose the router to extreme temperatures (hot or cold). Operate and store it within recommended environmental conditions.
• Reiniging: Brûk in sêfte, droege doek om de bûtenkant fan it apparaat skjin te meitsjen. Brûk gjin floeibere skjinmakkers of spuitbussen.
• Batterij soarch: For optimal battery life, avoid fully discharging the battery frequently. If storing for extended periods, charge the battery to about 50% and store in a cool, dry place.
• Foarkom fysike ynfloed: Protect the device from drops, bumps, and strong vibrations.

7. Probleemoplossing

If you encounter issues with your ASHATA 4G Portable Router, refer to the following troubleshooting tips:

• Gjin ynternetferbining:
  • Soargje derfoar dat de SIM-kaart goed ynfoege is en aktivearre is mei in data-abonnemint.
  • Check the signal strength indicator on the router's display. If signal is weak or absent, move to an area with better network coverage.
  • Restart the router by turning it off and then on again.
  • Verify that your connected device's Wi-Fi is enabled and connected to the correct SSID.
• Trage ynternetsnelheid:
  • Ferminderje it oantal ferbûne apparaten.
  • Move closer to the router to improve Wi-Fi signal strength.
  • Check for network congestion in your area or contact your SIM card provider.
• Kin net ferbine mei Wi-Fi:
  • Ensure you are entering the correct Wi-Fi password (Key).
  • Restart both the router and your connecting device.
  • Check if the router's display shows any error messages.
• Router Not Powering On:
  • Ensure the battery is charged. Connect the router to a power source using the Type-C cable.
  • Verify that the power cable and adapter are functioning correctly.

8. Spesifikaasjes

Detailed technical specifications for the ASHATA 4G Portable Router:

9. Garânsje en stipe

ASHATA products are manufactured to high-quality standards. This product is covered by a limited warranty against defects in materials and workmanship from the date of purchase. Please retain your proof of purchase for warranty claims.

For technical support, warranty inquiries, or further assistance, please refer to the contact information provided with your purchase documentation or visit the official ASHATA webside. Besykje it apparaat net sels te reparearjen, om't dit de garânsje ûnjildich meitsje kin.
